| Production |
| Manufacturer: | AGCO
|
| Type: | Row-Crop tractor
|
| Factory: | Beauvais, France
|
| AGCO RT150 Power |
| PTO (claimed): | 150 hp
111.9 kW
|
| Drawbar (tested): | 121.90 hp
90.9 kW
|
| PTO (tested): | 156.18 hp
116.5 kW
|
| Mechanical |
| Chassis: | 4x2 2WD
|
| | 4x4 MFWD 4WD (optional)
|
| Differential lock: | electro-hydraulic front and rear
|
| Steering: | hydrostatic power
|
| Brakes: | hydraulic wet disc
|
| Cab: | Cab standard with optional automatic climate control.
|
| Transmissions: | continuously variable transmission
|
| | 32-speed partial power shift
|
| Hydraulics |
| Type: | closed center pressure flow compensating (PFC)
|
| Pressure: | 2900 psi
200.0 bar
|
| Valves: | 4 or 5
|
| SCV flow: | 29 gpm
109.8 lpm
|
| Tractor hitch |
| Rear Type: | II/IIIN
|
| Control: | electronic lower-link
|
| Rear lift (at 24"/610mm): | 14,500 lbs
6577 kg
|
| | 12,500 lbs
5670 kg (CVT)
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Rear RPM: | 540/1000
|
| Front PTO: | optional
|
| Dimensions & Tires |
| Wheelbase: | 113.8 inches
289 cm
|
| Weight: | 14528 to 16415 pounds
|
| Electrical |
| Ground: | negative
|
| Charging system: | alternator
|
| Charging amps: | 120
|
| Batteries: | 2
|
| Battery volts: | 12
|
|
