ATC 200 Tractors

ATC 200
Power: 36 hp
Date of manufacture :
1954 - 1955
Production
Manufacturer:ATC
Type:Agricultural Crawler tractor
Factory:Churubusco, Indiana, USA
ATC 200 Power
Engine:36.5 hp
27.2 kW
Plows:3*14-inch
ATC 200 Engine
Mechanical
Chassis:crawler
Final drives:spur gear
Brakes:contracting band
Cab:Open operator station.
Transmission:3-speed gear
Power Take-off (PTO)
Rear PTO:transmission*Optional
Rear RPM:540
Dimensions & Tracks
Weight:4530 lbs
2054 kg
tracks
Full dimensions and tracks ...
200 Serial Numbers
1954:200-001
1955:200-002
Final:200-080

how to read serial numbers...

Belt Pulley
Diameter:6 inches
15 cm
Width:7 inches
17 cm
RPM:664
Speed:1043 ft/min
317.91 meters/min
