Allis Chalmers 7060 Tractors
|
|
Power: 192 hp
Date of manufacture : 1974 - 1981 |
Production |
Manufacturer: | Allis Chalmers
|
Type: | Row-Crop tractor
|
Factory: | West Allis, Wisconsin, USA
|
Total built: | 7,796
|
Original price: | $48,696
|
Mechanical |
Chassis: | 4x2 2WD
|
Final drives: | inboard planetary
|
Steering: | hydrostatic power
|
Brakes: | differential power wet disc
|
Cab: | Accousta cab standard, A/C optional. Accousta cab II available in 1978.
|
Transmissions: | 20-speed partial power shift
|
| 12-speed partial power shift
|
Photos |
| Allis Chalmers 7060 photos... |
Hydraulics |
Type: | closed center
|
Valves: | 2 or 3
|
Pump flow: | 22 gpm 83.3 lpm
|
Total flow: | 45 gpm 170.3 lpm
|
Steering flow: | 9.5 gpm 36.0 lpm
|
Tractor hitch |
Rear Type: | 3/2
|
Rear lift (at 24"/610mm): | 6,680 lbs 3030 kg
|
Power Take-off (PTO) |
Rear PTO: | independent
|
Rear RPM: | 1000
|
| 540/1000 (optional)
|
Dimensions & Tires |
Wheelbase: | 106 inches 269 cm
|
Weight: | 11530 to 14645 pounds
|
Front tire: | 11.00x16
|
Rear tire: | 18.4x38
|
Full dimensions and tires ... |
7060 Serial Numbers |
Location: | Above PTO shield
|
1974: | 1001
|
1975: | 1299
|
1976: | 2749
|
1977: | 4582
|
1978: | 6001
|
1979: | 6789
|
1980: | 7693
|
1981: | 8442
|
Final: | 9142
|
how to read serial numbers...
|
Electrical |
Ground: | negative
|
Batteries: | 2
|
| 4 (optional)
|
Battery volts: | 12
|
|
