Belarus 1005 Tractors

Belarus 1005
Power: 100 hp
Date of manufacture :
1995 - 1996
Production
Manufacturer:Belarus
Type:Row-Crop tractor
Factory:Minsk, Belarus
Variants
1005:2WD
1025:4WD
Belarus 1005 Power
Engine:100 hp
74.6 kW
PTO (claimed):92 hp
68.6 kW
Belarus 1005 Engine
Mechanical
Chassis:4x2 2WD
Final drives:spur gear
Differential lock:hydraulic
Steering:power
Brakes:mechanical disc
Cab:Cab standard.
Transmission:18-speed
Capacity
Fuel:34.3 gal
129.8 L
Hydraulic system:5.4 gal
20.4 L
Hydraulics
Type:open center
Capacity:5.4 gal
20.4 L
Pressure:2250 psi
155.1 bar
Valves:2 or 3
Pump flow:11.9 gpm
45.0 lpm
Tractor hitch
Rear Type:II
Control:position and draft control
Rear lift (at ends):4366 lbs
1980 kg
Power Take-off (PTO)
Rear PTO:independent
Rear RPM:540/1000 (1.375)
Engine RPM:540@1632
1000@1673
Dimensions & Tires
Wheelbase:98.4 inches
249 cm
Weight:8874 lbs
4025 kg
Front tire:9.50x20
Rear tire:16.9x38
Full dimensions and tires ...
Electrical
Charging system:alternator
Charging amps:50
Battery volts:12
