| Production |
| Manufacturer: | J.I. Case
|
| Type: | Row-Crop tractor
|
| Factory: | Racine, Wisconsin, USA
|
| Original price: | $5,600 (1960 )
|
| Variants |
| 800B: | diesel standard
|
| 801B: | diesel row-crop
|
| 802B: | diesel Western special
|
| 803B: | diesel high-crop
|
| 810B: | gas standard
|
| 811B: | gas row-crop
|
| 812B: | gas Western special
|
| 813B: | gas high-crop
|
| J.I. Case 801-B Power |
| Belt (claimed): | 54 hp
40.3 kW
|
| Drawbar (tested): | 51.38 hp
38.3 kW
|
| Belt (tested): | 54.42 hp
40.6 kW
|
| Mechanical |
| Chassis: | 4x2 2WD
|
| Steering: | power
|
| Brakes: | differential mechanical disc
|
| Cab: | Open operator station.
|
| Transmission: | 8-speed torque converter
|
| Photos |
| | J.I. Case 801-B photos... |
| Tractor hitch |
| Type: | Case Eagle Hitch
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Rear RPM: | 540 (1.375)
|
| Dimensions & Tires |
| Wheelbase: | 101.75 inches
258 cm (wide front)
|
| | 92.25 inches
234 cm (tricycle)
|
| Weight: | 6800 lbs
3084 kg
|
| Front tire: | 6.00-16
|
| Rear tire: | 15.5-38
|
| Full dimensions and tires ... |
| 801-B Serial Numbers |
| Location: | Serial number plate on the right side of the instrument panel.
|
photo of 801-B serial number
| |
