| Production |
| Manufacturer: | Challenger (a part of Caterpillar)
|
| Type: | Agricultural Crawler tractor
|
| Factory: | Peoria, Illinois, USA
|
| Original price: | $119,000 (1994 )
|
| Challenger 65C Power |
| Engine (gross): | 285 hp
212.5 kW
|
| Drawbar (claimed): | 225 hp
167.8 kW
|
| PTO (claimed): | 250 hp
186.4 kW
|
| Drawbar (tested): | 220.32 hp
164.3 kW
|
| PTO (tested): | 257.20 hp
191.8 kW
|
| Mechanical |
| Chassis: | crawler
|
| Steering: | power
|
| Brakes: | hydraulic wet disc
|
| Cab: | Cab standard.
|
| Transmission: | 10-speed full power shift
|
| Capacity |
| Fuel: | 209 gal
791.1 L
|
| Hydraulic system: | 29 gal
109.8 L
|
| Hydraulics |
| Type: | closed center
|
| Capacity: | 29 gal
109.8 L
|
| Pressure: | 2550 psi
175.8 bar
|
| Valves: | 4
|
| Pump flow: | 27 gpm
102.2 lpm
|
| | 35 gpm
132.5 lpm *Optional
|
| Steering flow: | 61.4 gpm
232.4 lpm
|
| Steering press.: | 6090 psi
419.9 bar
|
| Tractor hitch |
| Rear Type: | III/IV
|
| Rear lift: | 11,370 lbs
5157 kg
|
| Power Take-off (PTO) |
| Rear RPM: | 1000
|
| Dimensions & Tracks |
| Wheelbase: | 107.1 inches
272 cm
|
| Weight: | 32875 lbs
14912 kg
|
| 25-in track |
| Full dimensions and tracks ... |
| Electrical |
| Ground: | negative
|
| Charging system: | alternator
|
| Charging amps: | 115
|
| Batteries: | 2
|
| Battery CCA: | 750
|
| Battery volts: | 12
|
|
