Cub Cadet Ex2900 Tractors
 |
|
Power: 28 hp
Date of manufacture : 2008 - 2011 |
| Production |
| Distributor: | Cub Cadet
|
| Manufacturer: | Yanmar
|
| Type: | Compact Utility tractor
|
| Original price: | $16,289 (2009)
|
| Cub Cadet Ex2900 Power |
| Engine: | 28.7 hp
21.4 kW
|
| PTO (claimed): | 22.7 hp
16.9 kW
|
| Mechanical |
| Chassis: | 4x4 MFWD 4WD
|
| Steering: | power
|
| Brakes: | wet disc
|
| Cab: | Foldable ROPS standard. Optional steel cab.
|
| Transmission: | Hydrostatic
|
| Photos |
| | Cub Cadet Ex2900 photos... |
| Hydraulics |
| Type: | open center
|
| Pump flow: | 5.6 gpm
21.2 lpm
|
| Total flow: | 9.9 gpm
37.5 lpm
|
| Steering flow: | 4.3 gpm
16.3 lpm
|
| Tractor hitch |
| Rear Type: | I
|
| Rear lift (at 24"/610mm): | 1,100 lbs
498 kg
|
| Power Take-off (PTO) |
| Rear PTO: | live
|
| Rear RPM: | 540
|
| Mid RPM: | 2100
|
| Dimensions & Tires |
| Wheelbase: | 61 inches
154 cm
|
| Weight: | 2,550 lbs
1156 kg
|
| Front tire: | 7-14
|
| Rear tire: | 11.2-24
|
| Ex2900 Serial Numbers |
| Location: | Serial number tag on the right side of the Cub Cadet Yanmar Ex2900, above the front axle.
|
photo of Ex2900 serial number
|
| Electrical |
| Ground: | negative
|
| Battery volts: | 12
|
|
