Power: 10 hp Date of manufacture : 1967 - 1969
Production Manufacturer Cub Cadet (a part of International Harvester) Type Garden tractor Factory Louisville, Kentucky, USA Cub Cadet 105 Engine Cub Cadet 105 Transmission Mechanical Chassis 4x2 2WD Steering manual Brakes drum Cab Open operator station with vinyl-padded fiberglass seat. Photos Cub Cadet 105 photos... Hydraulics Type optional Pressure 400 psi 27.6 bar Pump flow 2.5 gpm 9.5 lpm Tractor hitch Type Cub Cadet three-point Power Take-off (PTO) Front PTO independent Clutch mechanical Front RPM 3600 Dimensions & Tires Wheelbase 43 inches 109 cm Weight 625 lbs 283 kg Front tire 4.80x4.00-8 Rear tire 6-12 Full dimensions and tires ... 105 Serial Numbers 1967 218010 1968 225056 1969 280840 Final 306085 How to read a serial number table... 105 Serial Location Serial number plate mounted on the rear drive housing. Electrical Ground negative Charging system generator Charging amps 15 Battery volts 12

Cub Cadet lawn tractors 100	Power: 10 hp	Date of manufacture : 1963 - 1965

Cub Cadet lawn tractors 102	Power: 10 hp	Date of manufacture : 1965 - 1967

Cub Cadet lawn tractors 104	Power: 10 hp	Date of manufacture : 1967 - 1969

Cub Cadet lawn tractors 105	Power: 10 hp	Date of manufacture : 1967 - 1969

Cub Cadet lawn tractors 106	Power: 10 hp	Date of manufacture : 1969 - 1971

Cub Cadet lawn tractors 107	Power: 10 hp	Date of manufacture : 1969 - 1971

Cub Cadet lawn tractors 108	Power: 10 hp	Date of manufacture : 1971 - 1974

Cub Cadet lawn tractors 109	Power: 10 hp	Date of manufacture : 1971 - 1974
