Deere 2550 Tractors

Deere 2550
Power: 72 hp[P]
Date of manufacture :
1983 - 1986
Production
Manufacturer:John Deere
Type:Utility tractor
Factory:Mannheim, Baden-Württemberg, Germany
Original price:$22,000 (1983 2WD )
Original price:$26,598 (1983 4WD )
John Deere 2550 Power
PTO (claimed):65 hp
48.5 kW
Drawbar (tested):55.38 hp
41.3 kW
PTO (tested):65.94 hp
49.2 kW
John Deere 2550 Engine
Mechanical
Chassis:4x2 2WD
 4x4 MFWD 4WD
Final drives:inboard planetary
Differential lock:mechanical rear
Steering:power
Brakes:differential hydraulic wet disc
Cab:Two-post fixed ROPS. Canopy available. Sound-Gard cab optional with available heat and air-conditioning.
Transmissions:8-speed partially synchronized
 16-speed partial power shift
 8-speed power shuttle
 12-speed partially synchronized
Photos
John Deere 2550 photos...
Hydraulics
Type:closed center
Pressure:2300 psi
158.6 bar
Rear valves:1 or 2
Pump flow:13 gpm
49.2 lpm
Tractor hitch
Rear Type:II/I
Control:load and depth control
Rear lift:2735 lbs
1240 kg
Power Take-off (PTO)
Rear PTO:independent
 live (with reverser)
Rear RPM:540
 540/1000*Optional
Engine RPM:540@2382
Dimensions & Tires
2WD Wheelbase:89.2 inches
226 cm
4WD Wheelbase:90 inches
228 cm
Weight:6800 to 8330 pounds
Front tire:7.50-16
2WD Rear tire:16.9-30
2550 Serial Numbers
Location:Right side of main tractor frame, above front axle.
Electrical
Ground:negative
Charging system:alternator
ROPS Charging amps:33
Cab Charging amps:55
Batteries:2
Battery volts:12
Battery AH:55
