Deere 6310SE Tractors

Deere 6310SE
Power: 100 hp
Date of manufacture :
1998 - 2003
Production
Manufacturer:John Deere
Type:Utility tractor
John Deere 6310SE Power
Engine (net):100 hp
74.6 kW
John Deere 6310SE Engine
Mechanical
Chassis:4x2 2WD
 4x4 MFWD 4WD
Differential lock:electro-hydraulic rear
Steering:power
Brakes:hydraulic wet disc
Trailer brakes:hydraulic*Optional
 pneumatic*Optional
Cab:Cab standard with heat. Optional air-conditioning.
Transmissions:12-speed synchronized
 16-speed power shuttle
 16-speed four-speed power shift
Capacity
Fuel:43.6 gal
165.0 L
 30.6 gal
115.8 L (LP Cab)
Hydraulic system:14.5 gal
54.9 L
Hydraulics
Type:load sensing
Capacity:14.5 gal
54.9 L
Pressure:2901 psi
200.0 bar
Valves:4*Optional
Pump flow:14.3 gpm
54.1 lpm
Tractor hitch
Rear Type:II
Control:electronic lower-link draft sensing
Rear lift:10319 lbs
4680 kg
Power Take-off (PTO)
Rear PTO:independent
Clutch:electro-hydraulic wet disc
Rear RPM:540
 540/1000
 540/540E/1000
Engine RPM:540@2124
1000@2208
540E@1684
Front PTO:independent
Clutch:electro-hydraulic wet disc
Front RPM:1000
Engine RPM:1000@2185
Dimensions & Tires
Wheelbase:94.5 inches
240 cm
Weight:8924 lbs
4047 kg
Front tire:13.6R24
Rear tire:16.9R34
Full dimensions and tires ...
6310SE Serial Numbers
Location:Serial number plate on the right side of the tractor’s frame.
Electrical
Ground:negative
Charging system:alternator
Charging amps:90
Battery volts:12
Battery AH:110
