| Production |
| Manufacturer: | John Deere
|
| Type: | Row-Crop tractor
|
| Factory: | Waterloo, Iowa, USA
|
| John Deere 8530 Power |
| Engine (gross): | 330 hp
246.1 kW
|
| Engine (max): | 360 hp
268.5 kW
|
| PTO (claimed): | 275 hp
205.1 kW
|
| Drawbar (tested): | 240.35 hp
179.2 kW
|
| PTO (tested): | 312.73 hp
233.2 kW
|
| Mechanical |
| Chassis: | 4x4 Independent Link Suspension (ILS) MFWD 4WD
|
| Steering: | power
|
| Brakes: | hydraulic wet disc
|
| Cab: | CommandView cab standard.
|
| Photos |
| | John Deere 8530 photos... |
| Capacity |
| Fuel: | 180 gal
681.3 L
|
| Hydraulic system: | 9.5 gal
36.0 L
|
| | 14.5 gal
54.9 L (with aux reservoir)
|
| Hydraulics |
| Type: | closed center pressure-flow compensating PFC
|
| Capacity: | 9.5 gal
36.0 L
|
| | 14.5 gal
54.9 L (with aux reservoir)
|
| Pressure: | 2990 psi
206.2 bar
|
| Valves: | 3 to 5
|
| Pump flow: | 31.7 gpm
120.0 lpm
|
| Total flow: | 60 gpm
227.1 lpm
|
| Tractor hitch |
| Rear Type: | IVN/III
|
| Rear lift (at 24"/610mm): | 18,326 lbs
8312 kg
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Rear RPM: | 1000
|
| | 540/1000 (optional)
|
| Engine RPM: | 540@1817
1000@2000
|
| Dimensions & Tires |
| Wheelbase: | 118.9 inches
302 cm
|
| Weight: | 26,800 lbs
12156 kg
|
| Full dimensions and tires ... |
| 8530 Serial Numbers |
| Location: | Rear of tractor
|
photo of 8530 serial number
| | 2006: | 1001
|
| 2007: | 10005
|
| 2008: | 20007
|
| 2009: | 40000
|
how to read serial numbers...
|
| Electrical |
| Ground: | negative
|
| Charging system: | alternator
|
| Charging amps: | 200
|
| Batteries: | 2
|
| Battery CCA: | 925
|
| Battery volts: | 12
|
|
