International Harvester Cub Tractors
 |
|
Power: 13 hp
Date of manufacture : 1964 - 1979 |
| Production |
| Manufacturer: | International Harvester
|
| Factory: | Louisville, Kentucky, USA
|
| Mechanical |
| Chassis: | 4x2 2WD
|
| Steering: | manual
|
| Brakes: | differential mechanical drum
|
| Cab: | Open operator station.
|
| Transmission: | 3-speed sliding gear
|
| Photos |
| | International Harvester Cub photos... |
| Capacity |
| Fuel: | 7.5 gal
28.4 L
|
| Hydraulic system: | 0.56 gal
2.1 L
|
| Hydraulics |
| Capacity: | 0.56 gal
2.1 L
|
| Pressure: | 1200 psi
82.7 bar
|
| Total flow: | 2.8 gpm
10.6 lpm
|
| Tractor hitch |
| Type: | IH Fast Hitch (optional)
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Rear RPM: | 1800 (counter-clockwise)
|
| Dimensions & Tires |
| Wheelbase: | 69.25 inches
175 cm
|
| Weight: | 1477 to 1877 pounds
|
| Front tire: | 4.00-12
|
| Rear tire: | 8-24
|
| Cub Serial Numbers |
| Location: | Serial number plate on the right side of the Farmall Cub, above the front axle.
|
photo of Cub serial number
| | 1964: | 224704
|
| 1965: | 225110
|
| 1966: | 227209
|
| 1967: | 229225
|
| 1968: | 231005
|
| 1969: | 232981
|
| 1970: | 234868
|
| 1971: | 236827
|
| 1972: | 238506
|
| 1973: | 240581
|
| 1974: | 242746
|
| 1975: | 246561
|
| Final: | 248124
|
| 1975: | 248125
|
| 1976: | 248618
|
| 1977: | 250832
|
| 1978: | 252109
|
| 1979: | 253136
|
| Final: | 253685
|
how to read serial numbers...
|
| Links |
| FarmallCub.com: Information, photos, and a message board | | ATIS Cub FAQ: Information on the Cub | | McCormick-Deering Farmall Cub: |
| Electrical |
| Ground: | negative
|
| Charging system: | generator
|
| | alternator (sn 248125)
|
| Battery volts: | 12
|
|
