International Harvester Titan 18-35 Tractors
|
|
Power: 38 hp[B]
Date of manufacture : 1912 - 1915 |
Production |
Manufacturer: | International Harvester
|
Type: | Standard-tread tractor
|
Factory: | Milwaukee, Wisconsin, USA
|
International Harvester Titan 18-35 Power |
Drawbar (claimed): | 18 hp 13.4 kW
|
Belt (claimed): | 35 hp 26.1 kW
|
International Harvester Titan 18-35 Engine |
Mechanical |
Chassis: | 4x2 2WD
|
Steering: | manual
|
Cab: | Open operator station with canopy.
|
Transmission: | 2-speed gear
|
Dimensions & Tires |
Weight: | 15700 to 16850 pounds
|
Front tire: | 38x9
|
Rear tire: | 63x22
|
Full dimensions and tires ... |
Titan 18-35 Serial Numbers |
1912: | TC101 (hit-miss)
|
1913: | TC103 (hit-miss)
|
Final: | TC103 (hit-miss)
|
1913: | TB101 (throttle)
|
1914: | TB220 (throttle)
|
Final: | TB238
|
1914: | TF101
|
1915: | TF171
|
Final: | TF218
|
how to read serial numbers...
|
Belt Pulley |
Diameter: | 24 inches 60 cm
|
Width: | 12.5 inches 31 cm
|
|
