J.I. Case 1690 Tractors

J.I. Case 1690
Power: 100 hp[P]
Date of manufacture :
1980 - 1983
Production
Manufacturer:J.I. Case
Type:Utility tractor
Factory:Meltham Mills, Huddersfield, England
Original price:$30,000 (1983 )
J.I. Case 1690 Power
PTO (claimed):90 hp
67.1 kW
Drawbar (tested):72.55 hp
54.1 kW
PTO (tested):90.39 hp
67.4 kW
J.I. Case 1690 Engine
Mechanical
Chassis:4x2 2WD
 4x4 MFWD 4WD
Steering:power
Brakes:hydraulic wet disc
Cab:Two-post ROPS. Cab optional.
Transmissions:12-speed synchromesh
 12-speed partial power shift
Photos
J.I. Case 1690 photos...
Hydraulics
Type:open center
Pump flow:20 gpm
75.7 lpm
Tractor hitch
Rear Type:II
Power Take-off (PTO)
Rear PTO:independent
Rear RPM:540/1000
Dimensions & Tires
Wheelbase:100.5 inches
255 cm
Weight:8755 lbs
3971 kg
Front tire:10.00-16
Rear tire:18.4-34
1690 Serial Numbers
Location:Serial number stamped into the top of the tractor's frame on the right side, next to the engine.
photo of 1690 serial number

1980:11120101
1981:11211841
1982:11213684
1983:11214373

how to read serial numbers...

Electrical
Ground:negative
Battery volts:12
