J.I. Case 310E Tractors

J.I. Case 310E
Power: 40 hp
Date of manufacture :
1961 - 1964
Production
Manufacturer:J.I. Case
Type:Agricultural Crawler tractor
J.I. Case 310E Power
Engine:42 hp
31.3 kW
Drawbar (claimed):30 hp
22.4 kW
Belt (claimed):36 hp
26.8 kW
Plows:3
Drawbar (tested):29.56 hp
22.0 kW
PTO (tested):36.89 hp
27.5 kW
J.I. Case 310E Engines
Mechanical
Chassis:crawler
Brakes:contracting band
Cab:Open operator station.
Transmission:3-speed gear
Photos
J.I. Case 310E photos...
Capacity
Fuel:17 gal
64.3 L
Hydraulic system:9 gal
34.1 L
Hydraulics
Type:open center
Capacity:9 gal
34.1 L
Pressure:1500 psi
103.4 bar
Pump flow:15 gpm
56.8 lpm
Tractor hitch
Rear lift:700 lbs
317 kg
Power Take-off (PTO)
Rear RPM:540 (1.375)
Engine RPM:540@1727
Dimensions & Tracks
Wheelbase:57 inches
144 cm
Weight:5300 to 7545 pounds
14-inch tracks
Full dimensions and tracks ...
Belt Pulley
Diameter:8.5 inches
21 cm
Width:6.5 inches
16 cm
RPM:1160
Speed:2581 ft/min
786.69 meters/min
