J.I. Case lawn tractors 150 Tractors

J.I. Case lawn tractors 150
Power: 10 hp
Date of manufacture :
1966 - 0000
Production
Manufacturer:J.I. Case
Type:Garden tractor
Factory:Winneconne, Wisconsin, USA
J.I. Case 150 Engine
Mechanical
Chassis:4x2 2WD
Steering:manual
Brakes:hydraulic
Cab:Open operator station
Transmission:hydraulic drive
Capacity
Fuel:1.25 gal
4.7 L
Dimensions & Tires
Wheelbase:46 inches
116 cm
Weight:705 lbs
319 kg
Front tire:6.50x8
Rear tire:8.50x12
150 Serial Numbers
Location:Serial number plate on dash, below and to the right of the steering column.
Electrical
Ground:negative
Charging system:starter-generator
Battery
Number:1
Volts:12
