John Deere 4066R Tractors
 |
|
Power: 65 hp
Date of manufacture : 0000 - 0000 |
| Production |
| Manufacturer: | John Deere
|
| Type: | Compact Utility tractor
|
| Factory: | Augusta, Georgia, USA
|
| Variants |
| 4066M: | base model
|
| 4066R: | deluxe model
|
| John Deere 4066R Power |
| Engine: | 65.9 hp
49.1 kW
|
| Gear PTO (claimed): | 54.2 hp
40.4 kW
|
| Hydro PTO (claimed): | 51.9 hp
38.7 kW
|
| Mechanical |
| Chassis: | 4x4 MFWD 4WD
|
| Final drives: | planetary
|
| Differential lock: | mechanical rear
|
| Steering: | power
|
| Cab: | Two-post folding ROPS. Cab optional with air-conditioning.
|
| Transmissions: | 12-speed power shuttle
|
| | hydrostatic
|
| Photos |
| | John Deere 4066R photos... |
| Capacity |
| ROPS Fuel: | 13 gal
49.2 L
|
| Cab Fuel: | 13.8 gal
52.2 L
|
| Hydraulic system: | 12.5 gal
47.3 L
|
| Hydraulics |
| Type: | open center
|
| Capacity: | 12.5 gal
47.3 L
|
| Pump flow: | 11.2 gpm
42.4 lpm
|
| Total flow: | 17.4 gpm
65.9 lpm
|
| Steering flow: | 6.2 gpm
23.5 lpm
|
| Tractor hitch |
| Rear Type: | I
|
| Control: | position control
|
| Rear lift (at ends): | 3130 lbs
1419 kg
|
| Rear lift (at 24"/610mm): | 2500 lbs
1134 kg
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Rear RPM: | 540 (1.375)
|
| Engine RPM: | 540@2400
540E@1750
|
| Dimensions & Tires |
| Wheelbase: | 73 inches
185 cm
|
| Weight: | 3770 to 4675 pounds
|
| Front tire: | 8.00-16
|
| Rear tire: | 13.6-28
|
| 4066R Serial Numbers |
| Location: | Serial number plate on the right side of the 4066R tractor frame, above the front axle.
|
photo of 4066R serial number
|
| Electrical |
| Ground: | negative
|
| Charging system: | alternator
|
| Charging amps: | 75
|
| Battery CCA: | 770
|
| Battery volts: | 12
|
|
