| Production |
| Manufacturer: | John Deere
|
| Type: | Compact Utility tractor
|
| Factory: | Augusta, Georgia, USA
|
| John Deere 4410 Power |
| Engine (gross): | 34.6 hp
25.8 kW
|
| PTO (claimed): | 30 hp
22.4 kW (gear)
|
| | 28.5 hp
21.3 kW (hydro)
|
| Mechanical |
| Chassis: | 4x4 MFWD 4WD
|
| Differential lock: | mechanical
|
| Steering: | power
|
| Brakes: | wet disc
|
| Cab: | Two-post ROPS. Foldable ROPS optional.
|
| Transmissions: | 12-speed power shuttle
|
| | hydrostatic
|
| Capacity |
| Fuel: | 10 gal
37.9 L
|
| Hydraulic system: | 6.3 gal
23.8 L (gear)
|
| | 6.8 gal
25.7 L (hydro)
|
| Front axle: | 4.7 qts
4.4 L
|
| Hydraulics |
| Type: | open center
|
| Capacity: | 6.3 gal
23.8 L (gear)
|
| | 6.8 gal
25.7 L (hydro)
|
| Pressure: | 2500 psi
172.4 bar
|
| Valves: | 5
|
| Pump flow: | 8.6 gpm
32.6 lpm
|
| Total flow: | 13.9 gpm
52.6 lpm
|
| Steering flow: | 5.3 gpm
20.1 lpm
|
| Tractor hitch |
| Rear Type: | I
|
| Rear lift (at 24"/610mm): | 2,200 lbs
997 kg
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Rear RPM: | 540
|
| Mid PTO: | optional
|
| Mid RPM: | 2100
|
| Dimensions & Tires |
| Wheelbase: | 68 inches
172 cm
|
| Weight: | 2,900 lbs
1315 kg
|
| Front tire: | 7.00-14
|
| Rear tire: | 11.2-24
|
| 4410 Serial Numbers |
| Location: | On right side of tractor frame above the front axle.
|
photo of 4410 serial number
| | 2002: | 140001
|
| 2003: | 240001
|
| 2004: | 340001
|
how to read serial numbers...
|
| Electrical |
| Ground: | negative
|
| Charging system: | alternator
|
| Charging amps: | 40
|
| | 55 (optional)
|
| Battery CCA: | 500
|
| Battery volts: | 12
|
|
