John Deere 6405 Tractors

John Deere 6405
Power: 94 hp[P]
Date of manufacture :
1998 - 2002
Production
Manufacturer:John Deere
Type:Utility tractor
Factory:Mannheim, Baden-Württemberg, Germany
Original price:$35,000 (1999 )
Mechanical
Chassis:4x2 2WD
 4x4 MFWD 4WD
Steering:power
Brakes:hydraulic wet disc
Cab:Two-post foldable ROPS. Advantage Cab optional with air-conditioning.
Transmissions:12-speed fully synchronized
 16-speed power shuttle
Photos
John Deere 6405 photos...
Hydraulics
Type:HydraVantage constant flow load sensing
Pressure:2500 psi
172.4 bar
Valves:2 to 4
Total flow:17.5 gpm
66.2 lpm
Tractor hitch
Rear Type:2
Control:position control with optional draft control
Rear lift:5,028 lbs
2280 kg
Power Take-off (PTO)
Rear PTO:independent
Rear RPM:540/1000
Engine RPM:540@2143
1000@2208
Dimensions & Tires
Wheelbase:94.5 inches
240 cm
Weight:7695 to 8987 pounds
Front tire:10.00-16
Rear tire:18.4-34 (2WD)
Full dimensions and tires ...
6405 Serial Numbers
Location:Serial number plate on the right side of the tractor frame, above the front axle.
1998:206000
1999:233700
2000:260600
2001:322099

how to read serial numbers...

Electrical
Ground:negative
Charging system:alternator
Charging amps:90
Battery CCA:830
Battery volts:12
