John Deere 6510L Tractors

John Deere 6510L
Power: 114 hp
Date of manufacture :
1999 - 2002
Production
Manufacturer:John Deere
Type:Orchard/Vineyard tractor
Factory:Mannheim, Baden-Württemberg, Germany
Variants
6510L:low-profile ROPS
6510S:low-profile cab
John Deere 6510L Power
Engine (gross):114 hp
85.0 kW
PTO (claimed):95 hp
70.8 kW
John Deere 6510L Engine
Mechanical
Chassis:4x2 2WD
 4x4 MFWD 4WD
Differential lock:electro-hydraulic wet disc
Steering:power
Brakes:hydraulic wet disc
Cab:Two-post folding ROPS.
Transmissions:16-speed four-speed power shift
 38-speed four-speed power shift
Hydraulics
Type:closed center load sensing
Pressure:2900 psi
200.0 bar
Valves:1 to 4
Pump flow:25.4 gpm
96.1 lpm
 18.9 gpm
71.5 lpm *Optional
Tractor hitch
Rear Type:II
Control:electronic lower-link draft sensing
Rear lift:5915 lbs
2683 kg
Power Take-off (PTO)
Rear PTO:independent
Rear RPM:540 (1.375)
 540/1000 (1.375)*Optional
Dimensions & Tires
Wheelbase:94.5 inches
240 cm
Weight:7740 to 8379 pounds
Front tire:27/9.5-15
2WD Rear tire:18.4-26
Full dimensions and tires ...
6510L Serial Numbers
Location:Serial number plate on the right side of the tractor frame.
Electrical
Ground:negative
Charging system:alternator
Charging amps:90
Battery CCA:850
 1230*Optional
Battery volts:12
Battery AH:110
 154*Optional
