| Production |
| Distributor: | Mahindra
|
| Manufacturer: | Mitsubishi
|
| Type: | Compact Utility tractor
|
| Original price: | $23,490 (2016 shuttle ROPS )
|
| Original price: | $24,480 (2016 hydrostatic ROPS )
|
| Original price: | $32,468 (2016 hydrostatic cab )
|
| Mahindra 1538 Power |
| Engine: | 38.7 hp
28.9 kW
|
| Shuttle PTO (claimed): | 29.9 hp
22.3 kW
|
| Hydro PTO (claimed): | 27.7 hp
20.7 kW
|
| Mechanical |
| Chassis: | 4x4 MFWD 4WD
|
| Steering: | power
|
| Brakes: | wet disc
|
| Cab: | Two-post foldable ROPS. Cab optional with air-conditioning.
|
| Transmissions: | 8-speed shuttle
|
| | hydrostatic
|
| Hydraulics |
| Type: | open center
|
| Rear valves: | 1*Optional
|
| Pump flow: | 7.7 gpm
29.1 lpm
|
| Steering flow: | 3.4 gpm
12.9 lpm
|
| Tractor hitch |
| Rear Type: | I
|
| Control: | position control
|
| Rear lift: | 2646 lbs
1200 kg
|
| Rear Arms: | telescopic stabilizers
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Rear RPM: | 540 (1.375)
|
| Engine RPM: | 540@2376
|
| Mid RPM: | 2000
|
| Engine RPM: | 2000@2525
|
| Dimensions & Tires |
| Weight: | 3175 to 3627 pounds
|
| Front tire: | 7x16
|
| Rear tire: | 11.2x24
|
| Electrical |
| Charging system: | alternator
|
| Charging amps: | 90
|
| Charging volts: | 12
|
| Battery volts: | 12
|
| Battery AH: | 46
|
|
