Mahindra 2310 Tractors

Mahindra 2310
Power: 25 hp
Date of manufacture : 2002 - 2006
Production
Distributor:Mahindra
Manufacturer:TYM
Type:Compact Utility tractor
Factory:South Korea
Mahindra 2310 Power
Engine:25 hp
18.6 kW
PTO (claimed):20 hp
14.9 kW
Mahindra 2310 Engine
Mechanical
Chassis:4x4 MFWD 4WD
Steering:hydrostatic power
Brakes:wet disc
Transmissions:12-speed synchomesh shuttle
 hydrostatic
Hydraulics
Type:open center
Gear Pump flow:5.88 gpm
22.3 lpm
Hydro Pump flow:6.3 gpm
23.8 lpm
Gear Steering flow:3.07 gpm
11.6 lpm
Hydro Steering flow:4.55 gpm
17.2 lpm
Tractor hitch
Rear Type:I
Control:position control
Gear Rear lift:2075 lbs
941 kg
Hydro Rear lift:2080 lbs
943 kg
Power Take-off (PTO)
Rear PTO:independent
Clutch:electro-hydraulic
Rear RPM:540
Engine RPM:540@2541 (gear)
540@2775 (hydro)
Mid PTO:independent (hydro only)
Clutch:electro-hydraulic
Mid RPM:2000
Engine RPM:2000@2650
Dimensions & Tires
Weight:3064 lbs
1389 kg
Electrical
Ground:negative
Charging system:alternator
Charging amps:50
Charging volts:12
Battery volts:12
Battery AH:75
