| Production |
| Manufacturer: | Mahindra
|
| Type: | Utility tractor
|
| Original price: | $32,060 (2013 ROPS )
|
| Original price: | $43,440 (2013 Cab )
|
| Mahindra 8560 Power |
| Engine: | 83 hp
61.9 kW
|
| PTO (claimed): | 70 hp
52.2 kW
|
| Mechanical |
| Chassis: | 4x2 2WD
|
| | 4x4 MFWD 4WD (optional)
|
| Steering: | hydrostatic power
|
| Brakes: | wet disc
|
| Cab: | Two-post foldable ROPS. Cab optional with air-conditioning.
|
| Transmission: | 12-speed synchromesh
|
| Photos |
| | Mahindra 8560 photos... |
| Hydraulics |
| Type: | open center
|
| Valves: | 2
|
| Pump flow: | 17 gpm
64.3 lpm
|
| Steering flow: | 5.3 gpm
20.1 lpm
|
| Tractor hitch |
| Rear Type: | 2
|
| Control: | position and draft control
|
| Rear lift: | 5,500 lbs
2494 kg
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Rear RPM: | 540/1000
|
| Engine RPM: | 540@2186
1000@2180
|
| Dimensions & Tires |
| Weight: | 6878 to 8122 pounds
|
| Front tire: | 11Lx15
|
| Rear tire: | 16.9x30 (2WD)
|
| Electrical |
| Ground: | negative
|
| Charging system: | alternator
|
| ROPS Charging amps: | 55
|
| Cab Charging amps: | 120
|
| Batteries: | 12
|
| Battery volts: | 12
|
| Battery AH: | 96
|
|
