Massey Ferguson 3225 Tractors
 |
|
Power: 68 hp
Date of manufacture : 1999 - 2001 |
| Production |
| Manufacturer: | Massey Ferguson
|
| Type: | Orchard/Vineyard tractor
|
| Massey Ferguson 3225 Power |
| Engine: | 68 hp
50.7 kW
|
| Massey Ferguson 3225 Engine |
| Mechanical |
| Chassis: | 4x2 2WD
|
| | 4x4 MFWD 4WD
|
| Differential lock: | electro-hydraulic rear
|
| Steering: | power
|
| Brakes: | hydraulic wet disc
|
| Cab: | Two-post mid-mount folding ROPS. Cab optional with air-conditioning.
|
| Transmissions: | 12-speed partially synchronized
|
| | 24-speed creeper
|
| Hydraulics |
| Type: | open center
|
| Pressure: | 2465 psi
170.0 bar
|
| Pump flow: | 14 gpm
53.0 lpm
|
| Tractor hitch |
| Rear Type: | II
|
| Control: | position and draft control
|
| Rear lift: | 5732 lbs
2600 kg
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Clutch: | dry disc
|
| Rear RPM: | 540/1000 (1.375)
|
| | 540/540E*Optional
|
| Engine RPM: | 540@1944
540E@1375
1000@1916
|
| Dimensions & Tires |
| 2WD Wheelbase: | 80.9 inches
205 cm
|
| 4WD Wheelbase: | 79.3 inches
201 cm
|
| Front tire: | 7.50-16
|
| 3225S 2WD Rear tire: | 14.9R24
|
| Full dimensions and tires ... |
| Electrical |
| Ground: | negative
|
| Charging system: | alternator
|
| Battery volts: | 12
|
| Battery AH: | 95
|
|
