McCormick Intl X10.50M Tractors
 |
|
Power: 49 hp
Date of manufacture : 2011 - 2014 |
| Production |
| Distributor: | McCormick Intl
|
| Manufacturer: | Daedong
|
| Type: | Compact Utility tractor
|
| Factory: | South Korea
|
| Variants |
| X10.50H: | hydrostatic
|
| X10.50M: | gear
|
| McCormick Intl X10.50M Power |
| Engine (gross): | 49 hp
36.5 kW
|
| PTO (claimed): | 41.7 hp
31.1 kW
|
| McCormick Intl X10.50M Engine |
| Mechanical |
| Chassis: | 4x4 MFWD 4WD
|
| Differential lock: | rear standard
|
| Steering: | hydrostatic power
|
| Brakes: | wet disc
|
| Cab: | Two-post ROPS.
|
| Transmission: | 12-speed synchronized shuttle
|
| Hydraulics |
| Type: | gear pump
|
| Valves: | 1 or 2
|
| Pump flow: | 16.8 gpm
63.6 lpm
|
| Tractor hitch |
| Rear Type: | I
|
| Control: | position and draft control
|
| Rear lift (at 24"/610mm): | 2,493 lbs
1130 kg
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Rear RPM: | 540
|
| Mid PTO: | optional
|
| Mid RPM: | 2000
|
| Dimensions & Tires |
| Wheelbase: | 74 inches
187 cm
|
| Weight: | 3,968 lbs
1799 kg
|
| Front tire: | 8-16
|
| Rear tire: | 13.6-24
|
| Electrical |
| Ground: | negative
|
| Battery volts: | 12
|
|
