Navigation: Home > Oliver > 1255

Oliver 1255 Tractors

Oliver 1255
Power: 42 hp[P]
Date of manufacture :
1969 - 1971
Production
Distributor:Oliver
Manufacturer:Fiat
Type:Utility tractor
Factory:Italy
Original price:$4,600 (1971 )
Mechanical
Chassis:4x2 2WD
 4x4 MFWD 4WD
Steering:manual
Steering:power*Optional
Brakes:mechanical band
Cab:Open operator station.
Transmissions:6-speed gear
 9-speed creeper
Photos
Oliver 1255 photos...
Capacity
Fuel:14.25 gal
53.9 L
Hydraulic system:4.5 gal
17.0 L
Hydraulics
Capacity:4.5 gal
17.0 L
Pressure:2133 psi
147.1 bar
Pump flow:5.76 gpm
21.8 lpm
 12 gpm
45.4 lpm *Optional, additional pump.
Tractor hitch
Rear Type:II/I
Control:position and draft control
Rear lift:2660 lbs
1206 kg
Power Take-off (PTO)
Rear PTO:live (two-stage clutch)
Rear RPM:540/ground (1.375)
Dimensions & Tires
2WD Wheelbase:75.625 inches
192 cm
4WD Wheelbase:71.375 inches
181 cm
Weight:3710 to 4300 pounds
Front tire:6.00-16
Rear tire:12.4-28
1255 Serial Numbers
1969:309-381
1970:312-957
1971:317-338
Final:318-385

how to read serial numbers...

Electrical
Ground:negative
Charging system:alternator
Charging amps:42
Batteries:2
Battery volts:6
