Production |
Manufacturer: | SAME
|
Type: | Compact Utility tractor
|
Original price: | $21,500 (1999)
|
Mechanical |
Chassis: | 4x4 MFWD 4WD
|
Steering: | hydrostatic power
|
Brakes: | mechanical wet disc
|
Cab: | Two-post ROPS. Cab optional.
|
Transmission: | 12-speed synchronized shuttle
|
Hydraulics |
Valves: | 1 (4 optional)
|
Pump flow: | 7.9 gpm 29.9 lpm
|
Tractor hitch |
Rear Type: | 1
|
Control: | position and draft control
|
Rear lift: | 2,645 lbs 1199 kg
|
Front Hitch: | 1 (optional)
|
Front lift: | 882 lbs 400 kg
|
Power Take-off (PTO) |
Rear PTO: | independent
|
Rear RPM: | 540/1000
|
Mid PTO: | optional
|
Front PTO: | optional
|
Dimensions & Tires |
Wheelbase: | 66.93 inches 170 cm
|
Weight: | 2,226 lbs 1009 kg
|
Front tire: | 7.50-16
|
Rear tire: | 360/70R24
|
Full dimensions and tires ... |
Electrical |
Ground: | negative
|
Battery volts: | 12
|
|
