| Production |
| Manufacturer: | TYM
|
| Type: | Compact Utility tractor
|
| TYM T233 Power |
| Engine (gross): | 23 hp
17.2 kW
|
| PTO (claimed): | 19.5 hp
14.5 kW
|
| Mechanical |
| Chassis: | 4x4 MFWD 4WD
|
| Steering: | hydrostatic power
|
| Brakes: | wet disc
|
| Cab: | Two-post ROPS.
|
| Transmission: | hydrostatic
|
| Photos |
| | TYM T233 photos... |
| Hydraulics |
| Type: | gear pump
|
| Valves: | 1
|
| Pump flow: | 5.0 gpm
18.9 lpm
|
| Total flow: | 7.6 gpm
28.8 lpm
|
| Tractor hitch |
| Rear Type: | I
|
| Rear lift (at ends): | 1,653 lbs
749 kg
|
| Rear lift (at 24"/610mm): | 1,213 lbs
550 kg
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Clutch: | electro-hydraulic
|
| Rear RPM: | 540 (1.375)
|
| Mid PTO: | independent
|
| Mid RPM: | 2000
|
| Dimensions & Tires |
| Wheelbase: | 58.3 inches
148 cm
|
| Weight: | 1,654 lbs
750 kg
|
| Front tire: | 6-12
|
| Rear tire: | 9.5-20
|
| Electrical |
| Ground: | negative
|
| Charging system: | alternator
|
| Charging amps: | 50
|
| Battery volts: | 12
|
|
