TYM T394 Tractors

TYM T394
Power: 37 hp
Date of manufacture :
0000 - 0000
Production
Manufacturer:TYM
Type:Compact Utility tractor
TYM T394 Power
Engine (gross):37.4 hp
27.9 kW
TYM T394 Engine
Mechanical
Steering:power
Brakes:wet disc
Cab:Two-post folding ROPS. Cab optional with air-conditioning.
Transmissions:12-speed shuttle
 hydrostatic
Hydraulics
Type:open center
Pump flow:6.4 gpm
24.2 lpm
Total flow:11 gpm
41.6 lpm
Steering flow:4.6 gpm
17.4 lpm
Tractor hitch
Rear Type:I
Control:position control
Rear lift (at ends):2646 lbs
1200 kg
Rear lift (at 24"/610mm):1764 lbs
800 kg
Power Take-off (PTO)
Rear PTO:independent
Rear RPM:540 (1.375)
Mid PTO:independent
Mid RPM:2000
Dimensions & Tires
Wheelbase:66.1 inches
167 cm
Weight:3020 lbs
1369 kg
Electrical
Ground:negative
Charging amps:55
Battery volts:12
