Navigation: Home > UTB/Universal > 330

UTB/Universal 330 Tractors

UTB/Universal 330
Power: 31 hp[P]
Date of manufacture :
0000 - 0000
Production
Manufacturer:UTB/Universal
Type:Utility tractor
UTB/Universal 330 Power
PTO (claimed):28 hp
20.9 kW (max)
UTB/Universal 330 Engine
Mechanical
Chassis:4x2 2WD
 4x4 MFWD 4WD
Final drives:spur gear
Differential lock:mechanical rear
Steering:power
Brakes:mechanical band
Cab:Two-post fixed ROPS.
Transmission:8-speed partially synchronized
Hydraulics
Type:open center
Pressure:2133 psi
147.1 bar
Pump flow:10 gpm
37.9 lpm
Tractor hitch
Rear Type:II//I
Rear lift:2650 lbs
1202 kg
Power Take-off (PTO)
Rear PTO:independent
Rear RPM:540 (1.375)
Engine RPM:540@1967
Dimensions & Tires
2WD Wheelbase:70.75 inches
179 cm
4WD Wheelbase:73.25 inches
186 cm
Weight:3200 to 3820 pounds
Front tire:6.50x16
2WD Rear tire:12.4x28
Full dimensions and tires ...
