UTB/Universal S445 Tractors
 |
|
Power: 46 hp[P]
Date of manufacture : 1972 - 1981 |
| Production |
| Manufacturer: | UTB/Universal
|
| Type: | Agricultural Crawler tractor
|
| Factory: | Brasov, Romania
|
| Variants |
| SV445: | narrow
|
| S445: | standard
|
| SM445: | wide-track
|
| U445: | wheeled tractor
|
| UTB/Universal S445 Power |
| PTO (claimed): | 42 hp
31.3 kW
|
| UTB/Universal S445 Engine |
| Mechanical |
| Chassis: | crawler
|
| Brakes: | band
|
| Cab: | Open operator station.
|
| Transmission: | 6-speed constant mesh
|
| Hydraulics |
| Type: | open center
|
| Pressure: | 2475 psi
170.7 bar
|
| Pump flow: | 5.8 gpm
22.0 lpm
|
| Tractor hitch |
| Rear Type: | II/I
|
| Rear lift: | 2650 lbs
1202 kg
|
| Power Take-off (PTO) |
| Rear RPM: | 540
|
| Engine RPM: | 540@1970
|
| Dimensions & Tracks |
| Wheelbase: | 51.9 inches
131 cm
|
| Weight: | 5600 lbs
2540 kg
|
| 250mm track (SV445) |
| Full dimensions and tracks ... |
| Electrical |
| Charging system: | alternator
|
| Battery volts: | 12
|
|
