Ursus 1224 Tractors

Ursus 1224
Power: 119 hp
Date of manufacture :
1984 - 2009
Production
Manufacturer:Ursus
Factory:Warsaw, Poland
Variants
1222:2WD
1224:4WD
Ursus 1224 Power
Engine:119 hp
88.7 kW
PTO (claimed):97 hp
72.3 kW
Ursus 1224 Engine
Mechanical
Chassis:4x4 MFWD 4WD
Steering:power
Brakes:hydraulic dry disc
Cab:Cab standard with heater.
Transmission:16-speed
Hydraulics
Pump flow:10.8 gpm
40.9 lpm
Tractor hitch
Rear Type:II
Control:position and draft control
Rear lift:12125 lbs
5499 kg
Power Take-off (PTO)
Rear PTO:independent
Rear RPM:540/1000 (1.375)
Dimensions & Tires
Wheelbase:106.1 inches
269 cm
Weight:10737 lbs
4870 kg
Front tire:14.9-24
Rear tire:18.4-34
Full dimensions and tires ...
Electrical
Charging system:alternator
Charging amps:42
Batteries:4
Battery volts:6
