Ursus 5714 Tractors

Ursus 5714
Power: 79 hp
Date of manufacture :
2002 - 2009
Production
Manufacturer:Ursus
Type:Utility tractor
Factory:Warsaw, Poland
Variants
5712:2WD
5714:4WD
Ursus 5714 Power
Engine:79.8 hp
59.5 kW
PTO (claimed):67.1 hp
50.0 kW
Ursus 5714 Engine
Mechanical
Chassis:4x4 MFWD 4WD
Differential lock:mechanical rear
Steering:power
Brakes:mechanical wet disc
Cab:Two-post ROPS. Cab optional with available heater.
Transmissions:8-speed
 12-speed
Capacity
Fuel:21.1 gal
79.9 L
Hydraulic system:11.6 gal
43.9 L
Steering:2.4 qts
2.3 L
Hydraulics
Capacity:11.6 gal
43.9 L
Pressure:2321 psi
160.0 bar
Pump flow:6.9 gpm
26.1 lpm
Steering cap.:2.4 qts
2.3 L
Tractor hitch
Rear Type:II
Control:Position and draft control
Rear lift:6173 lbs
2800 kg
 7055 lbs
3200 kg *With optional second lift ram.
Power Take-off (PTO)
Rear PTO:live
Rear RPM:540/1000 (1.375)
Engine RPM:540@1992
1000@2000
Dimensions & Tires
Wheelbase:91.7 inches
232 cm
Weight:7077 to 7837 pounds
Front tire:12.4R24
Rear tire:16.9R34
Full dimensions and tires ...
Electrical
Charging system:alternator
Charging amps:44
 55
Charging volts:12
Battery volts:12
Battery AH:120
