| Production |
| Manufacturer: | Valpadana
|
| Factory: | San Martino, Italy
|
| Valpadana 1540 Power |
| Engine: | 35.5 hp
26.5 kW
|
| PTO (claimed): | 32 hp
23.9 kW
|
| Mechanical |
| Chassis: | 4x4 MFWD 4WD
|
| Brakes: | Wet disc
|
| Cab: | cab with heat optional
|
| Transmissions: | 12-speed
|
| | 16-speed
|
| Hydraulics |
| Pressure: | 1595 psi
110.0 bar
|
| Valves: | 2 rear standard
|
| | 3 rear + 1 front optional
|
| Pump flow: | 7.4 gpm
28.0 lpm
|
| Total flow: | 12.6 gpm
47.7 lpm
|
| Steering flow: | 5.2 gpm
19.7 lpm
|
| Tractor hitch |
| Rear Type: | I
|
| Rear lift: | 2,646 lbs
1200 kg
|
| Front Hitch: | IN optional
|
| Front lift: | 881.8 lbs
399 kg
|
| Power Take-off (PTO) |
| Rear RPM: | 540/750
|
| Front PTO: | optional
|
| Front RPM: | 1000
|
| Dimensions & Tires |
| Wheelbase: | 67 inches
170 cm
|
| Weight: | 3,527 lbs
1599 kg
|
| Front tire: | 200/70-16
|
| Rear tire: | 320/70-20
|
| Full dimensions and tires ... | |
