| Production |
| Manufacturer: | Versatile (a part of Buhler)
|
| Type: | Four-wheel Drive (4WD) tractor
|
| Factory: | Winnipeg, Manitoba, Canada
|
| Mechanical |
| Chassis: | 4x4 articulated 4WD
|
| Final drives: | outboard planetary
|
| Steering: | articulated power
|
| Brakes: | wet disc
|
| Cab: | Cab standard with air-conditioning.
|
| Transmissions: | 12-speed partially synchronized
|
| | 12-speed full power shift
|
| Hydraulics |
| Type: | closed center load sensing
|
| Pressure: | 2900 psi
200.0 bar
|
| Valves: | 4
|
| | 5 (with 3-point hitch)
|
| Total flow: | 50 gpm
189.3 lpm
|
| Tractor hitch |
| Rear Type: | 4N/3
|
| Rear lift: | 13000 lbs
5896 kg
|
| Power Take-off (PTO) |
| Rear PTO: | independent*Optional
|
| Clutch: | electro-hydraulic wet disc
|
| Rear RPM: | 1000 (1.75)
|
| Dimensions & Tires |
| Wheelbase: | 133 inches
337 cm
|
| Weight: | 30,795 lbs
13968 kg
|
| Front tire: | 20.8R42
|
| Rear tire: | 20.8R42
|
| Full dimensions and tires ... |
| Electrical |
| Ground: | negative
|
| Charging amps: | 130
|
| Batteries: | 3
|
| Battery CCA: | 950
|
| Battery volts: | 12
|
|
