| Production |
| Manufacturer: | Zetor
|
| Factory: | Brno, Czechoslovakia
|
| Variants |
| 6711: | 2WD
|
| 6718: | 2WD cab
|
| 6745: | 4WD
|
| 6748: | 4WD cab
|
| Zetor 6745 Power |
| Engine: | 65 hp
48.5 kW
|
| PTO (claimed): | 60 hp
44.7 kW
|
| Mechanical |
| Chassis: | 4x4 MFWD 4WD
|
| Brakes: | differential hydraulic drum
|
| Trailer brakes: | air optional
|
| Cab: | Open operator station.
|
| Transmissions: | 10-speed
|
| | 20-speed partial power shift
|
| Photos |
| | Zetor 6745 photos... |
| Hydraulics |
| Type: | Zetormatic
|
| Pressure: | 2321 psi
160.0 bar
|
| Valves: | 1
|
| Pump flow: | 5.3 gpm
20.1 lpm
|
| Tractor hitch |
| Rear lift: | 3,858 lbs
1749 kg
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Rear RPM: | 540/ground
|
| | 1000*Optional
|
| Dimensions & Tires |
| Wheelbase: | 88.46 inches
224 cm
|
| Weight: | 6,695 lbs
3036 kg
|
| Front tire: | 11.2-24
|
| Rear tire: | 12.4-36
|
| Full dimensions and tires ... |
| 6745 Serial Numbers |
| Location: | Serial number plate on the left side of the Zetor 6745 dash, below the steering wheel.
|
photo of 6745 serial number
| |
