Power: 150 hp[P] Date of manufacture : 1994 - 1997
Production Manufacturer: AGCO Allis (a part of AGCO) Type: Row-Crop tractor Original price: $70,000 (1997 ) Variants 9435: 32-speed semi-powershift 9635: 18-speed full powershift AGCO Allis 9435 Power PTO (claimed): 135 hp 100.7 kW Drawbar (tested): 120.26 hp 89.7 kW PTO (tested): 143.78 hp 107.2 kW AGCO Allis 9435 Engine Mechanical Chassis: 4x2 2WD   4x4 MFWD 4WD Final drives: inboard planetary Differential lock: electro-hydraulic Steering: power Brakes: hydraulic wet disc Cab: Cab standard with air-conditioning. Transmission: 32-speed four-speed power shift Photos AGCO Allis 9435 photos... Hydraulics Type: closed center Pressure: 2900 psi 200.0 bar Valves: 3 or 4 Pump flow: 27 gpm 102.2 lpm Tractor hitch Rear Type: III/II Control: electronic lower-link draft sensing Rear lift (at 24"/610mm): 10400 lbs 4717 kg Rear Arms: extendible lower links Power Take-off (PTO) Rear PTO: independent Rear RPM: 540/1000 Dimensions & Tires 2WD Wheelbase: 123.2 inches 312 cm 4WD Wheelbase: 116.5 inches 295 cm Weight: 13800 to 15432 pounds Front tire: 11.00-16 2WD Rear tire: 18.4R38 Full dimensions and tires ... 9435 Serial Numbers Location: Console, right side 1994: 935001 1995: 935501 1996: 936301 1997: 936369 how to read serial numbers... Electrical Ground: negative Charging system: alternator Battery volts: 12

AGCO Allis 9130	Power: 150 hp[P]	Date of manufacture : 1991 - 1992

AGCO Allis 9150	Power: 166 hp[P]	Date of manufacture : 1991 - 1992

AGCO Allis 9170	Power: 192 hp[P]	Date of manufacture : 1991 - 1992

AGCO Allis 9190	Power: 214 hp[P]	Date of manufacture : 1991 - 1992

AGCO Allis 9435	Power: 150 hp[P]	Date of manufacture : 1994 - 1997

AGCO Allis 9455	Power: 172 hp[P]	Date of manufacture : 1994 - 1999

AGCO Allis 9630	Power: 150 hp[P]	Date of manufacture : 1993 - 1995

AGCO Allis 9635	Power: 150 hp[P]	Date of manufacture : 1994 - 1997

AGCO Allis 9650	Power: 172 hp[P]	Date of manufacture : 1994 - 1995
