| Production |
| Manufacturer: | AGCO Allis (a part of AGCO)
|
| Type: | Row-Crop tractor
|
| Original price: | $72,000 (1995 )
|
| AGCO Allis 9630 Power |
| PTO (claimed): | 135 hp
100.7 kW
|
| Drawbar (tested): | 120.01 hp
89.5 kW
|
| PTO (tested): | 144.71 hp
107.9 kW
|
| Mechanical |
| Chassis: | 4x2 2WD
|
| | 4x4 MFWD 4WD
|
| Final drives: | inboard planetary
|
| Differential lock: | electro-hydraulic
|
| Steering: | power
|
| Brakes: | hydraulic wet disc
|
| Cab: | Cab standard.
|
| Transmission: | 18-speed full power shift
|
| Photos |
| | AGCO Allis 9630 photos... |
| Hydraulics |
| Type: | closed center pressure-compensating
|
| Pressure: | 2250 psi
155.1 bar
|
| Valves: | 3
|
| Pump flow: | 24 gpm
90.8 lpm *Advertised. Flow during testing was 22.6 GPM.
|
| Tractor hitch |
| Rear Type: | III/II
|
| Control: | lower-link draft sensing
|
| Rear lift: | 7212 lbs
3271 kg *During testing, actual lift was 5913 pounds.
|
| | 8544 lbs
3875 kg *Claimed lift with optional assist cylinder. During testing, actual lift was 6962 pounds.
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Clutch: | hydraulic wet disc
|
| Rear RPM: | 540/1000
|
| Dimensions & Tires |
| 2WD Wheelbase: | 124 inches
314 cm
|
| 4WD Wheelbase: | 116.5 inches
295 cm
|
| Weight: | 14800 to 17028 pounds
|
| Front tire: | 11.00-16
|
| 2WD Rear tire: | 18.4R38
|
| Full dimensions and tires ... |
| 9630 Serial Numbers |
| Location: | Console, right side
|
| 1994: | 921001
|
| 1995: | 921501
|
how to read serial numbers...
|
| Electrical |
| Ground: | negative
|
| Charging system: | alternator
|
| Charging amps: | 105
|
| Batteries: | 2
|
| Battery CCA: | 580
|
| Battery volts: | 12
|
|
