| Production |
| Manufacturer: | AGCO Allis
|
| Type: | Row-Crop tractor
|
| Original price: | $112,000 (1998)
|
| AGCO Allis 9695 Power |
| PTO (claimed): | 195 hp
145.4 kW
|
| Mechanical |
| Chassis: | 4x4 MFWD 4WD
|
| Cab: | Cab standard.
|
| Transmission: | 18-speed full power shift
|
| Hydraulics |
| Type: | closed
|
| Valves: | 3
|
| Pump flow: | 26 gpm
98.4 lpm
|
| Tractor hitch |
| Rear Type: | II,III
|
| Rear lift: | 9900 lbs
4490 kg
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Rear RPM: | 1000
|
| Dimensions & Tires |
| Wheelbase: | 116.5 inches
295 cm
|
| Weight: | 16800 lbs
7620 kg
|
| Front tire: | 16.7R28
|
| Rear tire: | 18.4R-42D
|
| Full dimensions and tires ... |
| 9695 Serial Numbers |
| Location: | Console, right side
|
| 1994: | 991001
|
| 1995: | 901501
|
| 1996: | 902301
|
| 1997: | 992384
|
how to read serial numbers...
|
| Electrical |
| Ground: | negative
|
| Battery volts: | 12
|
|
