Branson 3510h Tractors

Branson 3510h
Power: 35 hp
Date of manufacture :
2005 - 2015
Production
Manufacturer:Branson
Variants
3510i:shuttle
3510h:hydrostatic
Branson 3510h Power
Engine (gross):35 hp
26.1 kW
Branson 3510h Engine
Mechanical
Chassis:4x4 MFWD 4WD
Steering:hydrostatic power
Brakes:wet disc
Cab:ROPS. Canopy optional.
Transmission:hydrostatic
Hydraulics
Total flow:11.6 gpm
43.9 lpm
Tractor hitch
Rear Type:I
Rear lift (at ends):2,756 lbs
1250 kg
Power Take-off (PTO)
Rear PTO:independent
Rear RPM:540/540E
Dimensions & Tires
Wheelbase:65 inches
165 cm
Weight:3,478 lbs
1577 kg
Front tire:7-16
Rear tire:12.4-24
Full dimensions and tires ...
