Production |
Manufacturer: | J.I. Case
|
Type: | Standard-tread tractor
|
Factory: | Racine, Wisconsin, USA
|
Total built: | 41
|
Original price: | $4,000
|
J.I. Case 40-72 Power |
Drawbar (claimed): | 40 hp 29.8 kW
|
Belt (claimed): | 72 hp 53.7 kW
|
Plows: | 8-10 (14-inch)
|
Drawbar (tested): | 55.14 hp 41.1 kW
|
Belt (tested): | 91.42 hp 68.2 kW
|
Mechanical |
Chassis: | 4x2 2WD
|
Steering: | manual
|
Cab: | Open operator station.
|
Transmission: | 2-speed gear
|
Dimensions & Tires |
Wheelbase: | 124 inches 314 cm
|
Weight: | 21,200 lbs 9616 kg
|
Rear tire: | 72x20
|
Full dimensions and tires ... |
Belt Pulley |
Diameter: | 19.5 inches 49 cm
|
Width: | 10.5 inches 26 cm
|
RPM: | 750
|
Speed: | 3,827 ft/min 1166.47 meters/min
|
|
