| Production |
| Manufacturer: | J.I. Case
|
| Type: | Utility tractor
|
| Factories: | Rock Island, Illinois, USA
|
| | Racine, Wisconsin, USA
|
| Total built: | 1,181
|
| Original price: | $4,500
|
| Mechanical |
| Chassis: | 4x2 2WD
|
| Steering: | power assist
|
| Brakes: | differential mechanical dry disc
|
| Cab: | Open operator station.
|
| Transmissions: | 8-speed torque converter
|
| | 12-speed
|
| | 8-speed
|
| | 4-speed gear
|
| Photos |
| | J.I. Case 630 photos... |
| Hydraulics |
| Type: | Dual-Control
|
| Tractor hitch |
| Type: | Case Eagle Hitch
|
| Power Take-off (PTO) |
| Rear PTO: | continuous
|
| | independent (Case-o-matic)
|
| Rear RPM: | 540 (1.375)
|
| | 540/1000 (1.375)
|
| Dimensions & Tires |
| Weight: | 4600 to 4800 pounds
|
| Front tire: | 7.50-16
|
| Rear tire: | 16.9-28
|
| Full dimensions and tires ... |
| 630 Serial Numbers |
| Location: | instrument panel
|
| 1960: | 6144001
|
| 1961: | 6162601
|
| 1962: | 8190001
|
| 1963: | 8208001
|
how to read serial numbers...
|
| Belt Pulley |
| Diameter: | 9.25 inches
23 cm
|
| Width: | 6 inches
15 cm
|
| Electrical |
| Ground: | positive
|
| Batteries: | 2
|
| Battery volts: | 6
|
|
