| Production |
| Manufacturer: | J.I. Case
|
| Type: | Standard-tread tractor
|
| Factory: | Racine, Wisconsin, USA
|
| Original price: | $5,700 (1969)
|
| Mechanical |
| Chassis: | 4x2 2WD
|
| Steering: | manual
|
| | power optional
|
| Cab: | Open operator station.
|
| Transmissions: | 8-speed torque converter
|
| | 8-speed unsynchronized
|
| Capacity |
| Fuel: | 31 gal
117.3 L
|
| Hydraulic system: | 17 gal
64.3 L
|
| Hydraulics |
| Type: | open center
|
| Capacity: | 17 gal
64.3 L
|
| Valves: | 4
|
| Pump flow: | 15.5 gpm
58.7 lpm
|
| Tractor hitch |
| Rear Type: | II
|
| Rear lift: | 1,350 lbs
612 kg
|
| Type: | Case Eagle Hitch
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Rear RPM: | 540
|
| | 1000
|
| Dimensions & Tires |
| Wheelbase: | 102 inches
259 cm
|
| Weight: | 7,000 lbs
3175 kg
|
| Front tire: | 6.00-16
|
| Rear tire: | 14.9-30
|
| Full dimensions and tires ... |
| 730 Serial Numbers |
| Location: | Plate on instrument panel
|
| 1960: | 8160001
|
| 1961: | 8168801
|
| 1962: | 8190001
|
| 1963: | 9208001
|
| 1964: | 8229001
|
| 1965: | 8253501
|
| 1966: | 8279001
|
| 1967: | 8306501
|
| 1968: | 8332101
|
| 1969: | 8356251
|
how to read serial numbers...
|
| Electrical |
| Ground: | negative
|
| Charging system: | generator
|
| Charging amps: | 20
|
| Batteries: | 2
|
| Battery CCA: | 70
|
| Battery volts: | 6
|
|
