CaseIH Maxxum 150 Tractors

CaseIH Maxxum 150
Power: 145 hp
Date of manufacture :
0000 - 0000
Production
Manufacturer:CaseIH
Type:Utility tractor
Original price:$124,679 (2017 )
Variants
Maxxum 150:standard
Maxxum 150MC:premium
CaseIH Maxxum 150 Power
Engine (gross):145 hp
108.1 kW
Engine (max):175 hp
130.5 kW
PTO (claimed):125 hp
93.2 kW
Drawbar (tested):97.1 hp
72.4 kW
PTO (tested):141.9 hp
105.8 kW
CaseIH Maxxum 150 Engine
Mechanical
Chassis:4x2 2WD
 4x4 MFWD 4WD
Final drives:inboard planetary
Steering:power
Brakes:hydraulic wet disc
Trailer brakes:hydraulic*Optional
 pneumatic*Optional
Cab:Cab standard with air-conditioning.
Transmission:16-speed partial power shift
Capacity
Fuel:51.5 gal
194.9 L
 57.5 gal
217.6 L *Optional, with auxiliary tank.
 60.8 gal
230.1 L *Optional, max tank.
Exhaust fluid (DEF):10.4 gal
39.4 L
Hydraulic system:19.5 gal
73.8 L
Hydraulics
Type:open center
 pressure-flow compensated*Optional
Capacity:19.5 gal
73.8 L
Rear valves:2 to 4
Mid valves:0 to 3
Pump flow:21.1 gpm
79.9 lpm
 29.8 gpm
112.8 lpm *Optional, PFC system.
SCV flow:19.8 gpm
74.9 lpm
Total flow:33.5 gpm
126.8 lpm
 42.2 gpm
159.7 lpm *With optional PFC system.
Steering flow:12.4 gpm
46.9 lpm
Tractor hitch
Rear Type:II
 IIIN/II*Optional
Control:electronic lower-link draft sensing
Rear lift (at 24"/610mm):6200 lbs
2812 kg
 6900 lbs
3129 kg *Optional
Rear Arms:telescopic link ends
Front Hitch:optional
Drawbar:Cat. 3
Power Take-off (PTO)
Rear PTO:independent
Rear RPM:540/1000 (1.375)
Front PTO:independent*Optional
Clutch:1000:1895
Front RPM:1000 (1.375)
Dimensions & Tires
2WD Wheelbase:104.4 inches
265 cm
4WD Wheelbase:104 inches
264 cm
Weight:12280 to 12831 pounds
Front tire:380/85R28
Rear tire:460/85R38
Full dimensions and tires ...
Electrical
Charging amps:120
 150*Optional
 200*Optional
Battery CCA:800
 1300*Optional
Battery volts:12
Battery AH:176
