Claas Arion 450 Tractors

Claas Arion 450
Power: 125 hp
Date of manufacture :
0000 - 0000
Production
Manufacturer:Claas
Type:Row-Crop tractor
Claas Arion 450 Power
Engine (gross):126 hp
94.0 kW
Engine (max):130 hp
96.9 kW
Claas Arion 450 Engine
Mechanical
Chassis:4x4 MFWD 4WD
Differential lock:electro-hydraulic
Cab:Cab standard. Air-conditioning optional.
Transmission:16-speed four-speed power shift
Hydraulics
Type:open center
 closed center load-sensing*Optional
Pressure:2756 psi
190.0 bar
Valves:2 to 4
Pump flow:15.85 gpm
60.0 lpm
 25.9 gpm
98.0 lpm *Optional, open center
 29.1 gpm
110.1 lpm *Optional, load sensing
Tractor hitch
Rear Type:III
Rear lift (at ends):9259 lbs
4199 kg
Front lift:6173 lbs
2800 kg
Power Take-off (PTO)
Rear PTO:independent
Clutch:wet disc
Rear RPM:540/540E
 540/540E/1000*Optional
Front PTO:independent*Optional
Front RPM:1000
Dimensions & Tires
Wheelbase:99.4 inches
252 cm
Weight:11240 lbs
5098 kg
Front tire:14.9R28
Rear tire:18.4R38
Electrical
Ground:negative
Charging system:alternator
Battery volts:12
