| Production |
| Manufacturer: | Cockshutt
|
| Type: | Row-Crop tractor
|
| Factory: | Charles City, Iowa, USA
|
| Original price: | $4,345 (1967 )
|
| Variants |
| Wheatland: | standard (wide) front axle
|
| High-crop: | high-clearance model
|
| Orchard: | low profile model
|
| Cockshutt 770 Power |
| PTO (claimed): | 47 hp
35.0 kW
|
| Plows: | 3-4
|
| Drawbar (tested): | 44.38 hp
33.1 kW
|
| Belt (tested): | 50.04 hp
37.3 kW
|
| Mechanical |
| Chassis: | 4x2 2WD
|
| Steering: | manual
|
| Brakes: | disc
|
| Cab: | Open operator station.
|
| Transmissions: | 6-speed sliding gear
|
| | 12-speed
|
| Photos |
| | Cockshutt 770 photos... |
| Tractor hitch |
| Rear Type: | I/II
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Dimensions & Tires |
| Weight: | 5500 lbs
2494 kg
|
| Front tire: | 6.00-16
|
| Rear tire: | 15.5-38
|
| Full dimensions and tires ... |
| 770 Serial Numbers |
| Location: | Bottom of dashboard below steering wheel.
|
| 1958: | 60504
|
| 1959: | 71001
|
| 1960: | 84554
|
| 1961: | 111472
|
| 1962: | 117600
|
| 1963: | 127319
|
| 1964: | 141901
|
| 1965: | 153255
|
| 1966: | 171515
|
| 1967: | 183649
|
| Last: | 193365
|
how to read serial numbers...
|
| Electrical |
| Ground: | positive
|
| Charging system: | generator
|
| Battery volts: | 12
|
|
