| Production |
| Manufacturer: | Cockshutt
|
| Factory: | Brantford, Ontario, Canada
|
| Total built: | 2,910
|
| Original price: | $5,000 (1961 )
|
| Cockshutt 560 Power |
| Drawbar (claimed): | 45 hp
33.6 kW
|
| PTO (claimed): | 49 hp
36.5 kW
|
| Plows: | 4
|
| Drawbar (tested): | 45.61 hp
34.0 kW
|
| Belt (tested): | 48.52 hp
36.2 kW
|
| Mechanical |
| Chassis: | 4x2 2WD
|
| Steering: | power assist
|
| Brakes: | mechanical disc
|
| Cab: | Open operator station.
|
| Transmission: | 6-speed unsynchronized gear
|
| Photos |
| | Cockshutt 560 photos... |
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Rear RPM: | 540
|
| Dimensions & Tires |
| Tricycle Wheelbase: | 90.75 inches
230 cm
|
| Row-crop Wheelbase: | 95.75 inches
243 cm
|
| Standard Wheelbase: | 97.75 inches
248 cm
|
| Weight: | 7200 lbs
3265 kg
|
| Front tire: | 6.00x16
|
| Rear tire: | 13.6/12x38
|
| Full dimensions and tires ... |
| 560 Serial Numbers |
| Location: | Right side of frame
|
| 1958: | CM1001
|
| 1959: | CN5001
|
| 1960: | CO7001
|
| 1961: | CP1001
|
how to read serial numbers...
| |
