Cub Cadet Sc2400 Tractors
 |
|
Power: 24 hp
Date of manufacture : 2008 - 2011 |
| Production |
| Distributor: | Cub Cadet
|
| Manufacturer: | Yanmar
|
| Type: | Sub-Compact Utility tractor
|
| Original price: | $11,499 (2009)
|
| Variants |
| Sc2400 TD: | includes 60-inch mid-mount mower
|
| Sc2400 TL: | includes loader
|
| Sc3400 TLD: | includes mower and loader
|
| Sc2450: | tractor backhoe
|
| Cub Cadet Sc2400 Power |
| Engine: | 24 hp
17.9 kW
|
| PTO (claimed): | 16.5 hp
12.3 kW
|
| Mechanical |
| Chassis: | 4x4 MFWD 4WD
|
| Steering: | power
|
| Brakes: | wet disc
|
| Cab: | ROPS standard. Optional steel cab.
|
| Transmission: | hydrostatic
|
| Photos |
| | Cub Cadet Sc2400 photos... |
| Hydraulics |
| Type: | open center
|
| Pump flow: | 3.5 gpm
13.2 lpm
|
| Total flow: | 7.1 gpm
26.9 lpm
|
| Steering flow: | 3.6 gpm
13.6 lpm
|
| Tractor hitch |
| Rear Type: | 1 (limited)
|
| Rear lift (at 24"/610mm): | 661 lbs
299 kg
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Rear RPM: | 540
|
| Mid PTO: | independent
|
| Mid RPM: | 2100
|
| Dimensions & Tires |
| Wheelbase: | 55.1 inches
139 cm
|
| Weight: | 1,280 lbs
580 kg
|
| Front tire: | 18x8.5-10
|
| Rear tire: | 26x12.0-12
|
| Sc2400 Serial Numbers |
| Location: | Serial number plate on the right side of the Sc2400 frame, above the front axle.
|
photo of Sc2400 serial number
|
| Electrical |
| Charging system: | alternator
|
| Charging amps: | 40
|
|
