| Production |
| Manufacturer: | John Deere
|
| Type: | Utility tractor
|
| Factory: | Montenegro, Brazil
|
| John Deere 5605 Power |
| Engine: | 75 hp
55.9 kW
|
| PTO (claimed): | 65 hp
48.5 kW
|
| Mechanical |
| Chassis: | 4x2 2WD
|
| | 4x4 MFWD 4WD (optional)
|
| Steering: | hydrostatic power
|
| Brakes: | hydraulic wet disc
|
| Cab: | Two-post ROPS.
|
| Transmission: | 9-speed
|
| Capacity |
| Fuel: | 27.7 gal
104.8 L
|
| Hydraulic system: | 10.6 gal
40.1 L
|
| Hydraulics |
| Type: | open center gear pump
|
| Capacity: | 10.6 gal
40.1 L
|
| Pressure: | 2756 psi
190.0 bar
|
| Valves: | 2
|
| Pump flow: | 11.36 gpm
43.0 lpm
|
| SCV flow: | 10.57 gpm
40.0 lpm
|
| Oil type: |
|
| Steering flow: | 6.9 gpm
26.1 lpm
|
| Tractor hitch |
| Rear Type: | II
|
| Control: | position and depth control
|
| Rear lift (at ends): | 6,805 lbs
3086 kg
|
| Rear lift (at 24"/610mm): | 3,968 lbs
1799 kg
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Clutch: | mechanical dry disc
|
| Rear RPM: | 540
|
| Dimensions & Tires |
| Wheelbase: | 85.7 inches
217 cm
|
| Weight: | 5952 to 6393 pounds
|
| Front tire: | 7.50-16
|
| Rear tire: | 18.4-30 (2WD)
|
| Full dimensions and tires ... |
| Electrical |
| Ground: | negative
|
| Charging system: | alternator
|
| Charging amps: | 52
|
| Battery volts: | 12
|
| Battery AH: | 100
|
|
