| Production |
| Manufacturer: | Farmall (a part of International Harvester)
|
| Type: | Row-Crop tractor
|
| Factory: | Rock Island, Illinois, USA
|
| Total built: | 40,957
|
| Original price: | $3,500 (1954)
|
| Variants |
| 400: | row-crop
|
| W-400: | standard
|
| 400 Hi-Clear: | high-crop
|
| Farmall 400 Power |
| Drawbar (claimed): | 37 hp
27.6 kW
|
| PTO (claimed): | 45 hp
33.6 kW
|
| Drawbar (tested): | 48.12 hp
35.9 kW
|
| Belt (tested): | 52.36 hp
39.0 kW
|
| Mechanical |
| Chassis: | 4x2 2WD
|
| Steering: | manual
|
| | power optional
|
| Brakes: | manual disc
|
| Cab: | Open operator station.
|
| Transmission: | 10-speed partial power shift
|
| Photos |
| | Farmall 400 photos... |
| Capacity |
| Fuel: | 21.5 gal
81.4 L
|
| Aux. fuel: | 0.9 gal
3.4 L
|
| Hydraulic system: | 3.5 gal
13.2 L
|
| | 3.63 gal
13.7 L (power steering)
|
| Hydraulics |
| Type: | Hydra-Touch
|
| Capacity: | 3.5 gal
13.2 L
|
| | 3.63 gal
13.7 L (power steering)
|
| Valves: | 3
|
| Tractor hitch |
| Type: | IH Fast Hitch (optional)
|
| Rear lift: | 2,000 lbs
907 kg
|
| Power Take-off (PTO) |
| Rear PTO: | transmission
|
| | independent (optional)
|
| Rear RPM: | 540
|
| Engine RPM: | 537@1450 (trans.)
534@1450 (ind.)
|
| Dimensions & Tires |
| Wheelbase: | 95.75 inches
243 cm
|
| Weight: | 6,300 lbs
2857 kg
|
| Front tire: | 6.00-16
|
| Rear tire: | 12-38
|
| Full dimensions and tires ... |
| 400 Serial Numbers |
| Location: | Left side of clutch housing
|
photo of 400 serial number
| | 1954: | 501
|
| 1955: | 4732
|
| 1956: | 29065
|
how to read serial numbers...
|
| Belt Pulley |
| Diameter: | 11 inches
27 cm
|
| Width: | 7.5 inches
19 cm
|
| RPM: | 899
|
| Speed: | 2,588 ft/min
788.82 meters/min
|
| Electrical |
| Ground: | positive (6V)
|
| | negative (12V)
|
| Charging system: | generator
|
| Battery volts: | 6 (gas)
|
| | 12 (diesel)
|
|
